Solar Panels

Solar panels are devices for capturing the energy in sunlight.

Solar photovoltaic panels contain arrays of solar cells that convert light into electricity.

They are called solar after the sun or "Sol" because the sun is the most powerful source of the light available for use.

The solar cells are sometimes called photovoltaic cells, photovoltaic meaning literally "light-electricity".

With over 25 years of experience in the industry, at The 12 Volt Shop we pride ourselves on our range of solar panels and the knowledge of our staff.

We are the Australian experts in solar equipment for mobile applications such as caravans or motor home's.

Come in and see us or call us about our solar panels!

Mono crystalline vs Polycrystalline Solar Panels:

Busting Myths

One of the most common comments that our specialist team hear from customers relates to the issue of mono crystalline vs polycrystalline (or ‘multi crystalline’) solar panels. Although mono crystalline panels had the initial advantage of being seen as the superior technology in the Australian market, as time goes on and both technologies improve, it becomes increasingly apparent that the the quality and reliability of the manufacturer is far more important than which of the two technologies is chosen.

Monocrystalline cells are made from a single crystal of ultra pure silicon. They are the original silicon solar cell and they are still the most efficient today. Mono cells are typically a little more expensive since they’re a little more difficult to manufacture. The benefit of mono cells is that they perform slightly better under low light conditions equating to better production on cloudy days versus polycrystalline panels. How much better?. Suffice to say, you may get up to about 0.5% better production per annum using mono cells versus using polycrystalline.

Polycrystalline cells are made up of multiple crystals and are generally less expensive to manufacture than mono cells. The gap in performance has narrowed significantly over the years to the point where they are very close. Since Polycrystalline panels are made up of several crystals, this means that they also absorb less sunlight and produce slightly less than mono cells per metre squared.

Single crystal silicon is more efficient at converting photons to electrons for electricity, the poly-silicon its much less efficient because electrons are captured or generated less efficiently where the crystals of silicon touch. However, even though poly solar panels are not as efficient, they are cheaper to manufacture so they can still be competitive on a $/watt basis. They would just need more area to produce the same amount of electricity as the mono-crystalline panels.

Even though a mono crystalline panel has the potential to last up to 50 years, most warranties only go up to 25 years which polycrystalline panels are able to reach just fine.

Overall, the production process for mono crystalline silicon is mature, and the process for polycrystalline in still maturing. As purity and process tolerances for polycrystalline improves, the performance gaps between the two are narrowing.



Yingli Solar Panels

As one of the world's largest solar panel manufacturer, Yingli Solar is a leader in solar PV technology. With almost 10% global market share, more homes and businesses around the world are choosing Yingli Solar than any other PV brand.

Featuring world-class technology, high-quality workmanship and robust construction, our solar panels are designed to withstand harsh Australian conditions.

Ranked amongst the five best solar panels in world by PHOTON and TÜV Rheinland, solar panel reviews have rated Yingli Solar panels highly for our performance, quality and durability.

Yingli Green Energy is a leading solar energy company and one of the world’s first fully vertically integrated photovoltaic manufacturers.


They develop, manufacture, and sell high-quality modules under the brand Yingli Solar to a wide range of markets, including Germany, Australia, Spain, Italy, Greece, France, South Korea, China, and the United States.

Yingli Solar have been the industry leaders for solar panel production for the last 3 years, with production increasing each year.



CLICK HERE TO READ MORE ABOUT YINGLI SOLAR AND THE RIGOROUS TESTING THEIR PANELS GO THROUGH

Model No.
SPYL175
SPYL215
Application
Grid Connect / Caravan & Motorhome Battery Charging via MPPT Regulator
Rated Power (Watts)
175W
215W
Rated Voltage (Vmpp)
23.0V
29.0V
Rated Current (Impp)
7.61A
7.41A
Open Circuit Voltage (VOC)
29.0V
36.0V
Short Circuit Current (Isc)
8.2A
8.10A
No. of Cells
48
60
Dimensions MM (LxWxH)
1310x990x50mm
1650x990x50mm
Weight
16.0KG
20KG
Nominal Battery System Voltage
12V, 24V, 36V, 48V via MPPT Solar Charge Controller



SHARP Solar Panels *

Logo*NOT SUPPLIED ANYMORE - LIMITED STOCK AVAILABLE

With over 40 years experience providing innovative technology, Sharp leads in solar power generation.

This single crystal 185watt module features 15.9% encapsulated cell efficiency and 14.1% module efficiency. Using breakthrough technology perfected in Sharp’s space cell program, the NU-185A1H module allows for maximum usable power per square metre of solar array.
A safe, clean, reliable source of energy, Sharp’s NU-185A1H photovoltaic module is designed for large electrical power requirements. Based on the technology of crystal silicon solar cells developed over 50 years, this module has superb durability to withstand rigorous operating conditions and is suitable for grid connected systems.
Common applications for the Sharp NU-185A1H include residences, office buildings, solar power stations and solar suburbs. As one of the world’s leading manufacturer of photovoltaic modules, Sharp produces an extensive line of high power modules for every electrical power requirement.

Features

*NOT SUPPLIED ANYMORE - LIMITED STOCK AVAILABLE

Specifications

Cell Single-crystalline silicon solar cells: 155.55 mm square
No. of cells and connections: 48 in series
Application: Grid Connect / Only Off-Grid / Battery Charging when used with MPPT Regulator
Maximum system voltage: DC 1000V
Series fuse rating: 15A
Maximum power: 185.0w
Dimensions: 1318 x 994 x 46 mm
Weight: 16 Kg


Specifications
NU-185A1H
Cell Multi-crystalline silicon solar, 155.5mm square
No. of Cells and Connections 48 in seriess
Open Circuit Voltage (Voc) 30.2V
Maximum Power Voltage (Vpm) 24V
Short Circuit Current (Isc) 8.54A
Maximum Power Current (Ipm) 7.71A
Maximum Power (Minimum Power) (Pm) 185W
Encapsulated Solar Cell Efficiency (nc) 15.9%
Module Efficiency (nm) 14.1%
Maximum System Voltage DC 1000V
Series Fuse Rating 15A
Type of Output Terminal Lead- MC3 Compatible
Dimensions (LxWxD)mm 1318X994X46
Weight 16.0kg



MC4 Connectors and Pre-Assembled Leads

Second generation PV connector from Multi-Contact, which has rapidly become the most accepted connector in the world, designed to accept 4-6mm2 solar cable.

All Solar Panels are now generally coming with leads on the back with these types of Multi-Contact Connectors. Some smaller modules still have junction boxes, but any panel 80w and above will come with MC Connectors.

Features:

Our pre-assembled leads are made in house, from high quality Australian Made TUV PV1-F approved SOLX PV1-F Cable fitted with genuine Multi-Contact male and female connectors.

Connector System
Ø 4mm
Rated Voltage

1000V DC (IEC)

600V DC (UL)

Rated Current

30A (4mm2, 6mm2; 10AWG)

Test Voltage
6kV (50Hz, 1min.)
Ambient Temperature Range

-40°C...+90°C (IEC)

-40°C...+75°C (UL)

-40°C...+70°C (UL: 14AWG)

Upper Limiting Temperature
105°C (IEC)

Degree of Protection: Mated / Unmated

IP67 / IP2X

Over voltage Category / Pollution Degree
CATIII/2
Contact Resistance of Plug Connectors
0.5mΩ
Safety Class
II
Contact System

MC Multi lam

Type of Termination
Crimping
Contact Material
Copper, tin plated
Insulation Material
PC/PA
Locking System
Snap-in
Flame Class
UL94-V0
Cable strain relief according to
EN 50521:2008

MC4 Connectors
SOCPV-KBT4/6II-MC4 Male $10.50 Buy this product from our online store
SOCPV-KST4/6II-MC4 Female $10.50 Buy this product from our online store
MC4 Pre-Assembled Leads
SOCMC4L1M MC4 M-F 1m 4mm2 $29.99 Buy this product from our online store
SOCMC4L2M MC4 M-F 2m 4mm2 $32.99 Buy this product from our online store
SOCMC4L3M MC4 M-F 3m 4mm2 $35.99 Buy this product from our online store
SOCMC4L4M MC4 M-F 4m 4mm2 $38.99 Buy this product from our online store
SOCMC4L5M MC4 M-F 5m 4mm2 $40.99 Buy this product from our online store
SOCMC4L6M MC4 M-F 6m 4mm2 $43.99 Buy this product from our online store
SOCMC4L8M MC4 M-F 8m 4mm2 $51.99 Buy this product from our online store
SOCMC4L10M MC4 M-F 10m 4mm2 $59.99 Buy this product from our online store
